A room controller that speaks IP.
A desktop capacitive touch panel running Android 9 on a quad-core A53. One PoE cable carries power and the control network; RS-485, a service port and a reset sit alongside. Build the interface once and drive the whole room, over IP and over serial.
| CPU | ARM Cortex-A53, 1.8 GHz |
|---|---|
| OS | Android 9 |
| Memory | 2 GB DDR4 |
| Storage | 8 GB eMMC |
| Display | 10″, 1280 × 800, 450 nits |
| Touch | Capacitive |
| Network | 10/100/1000 RJ45, PoE |
| Serial | RS-485, 3-pin Phoenix |
| Service | Micro-USB |
| Power | 24 V DC / 1A, or PoE |
| Consumption | 6 W max |
| Operating temp. | 0 – 40 °C |
Tell us the sources, screens and distances in your install — we’ll confirm the right fit and send pricing.
